Compact Planetary Gearbox Assembly
$890 – $2,400
Fully assembled single-stage planetary sets — sun, planets, ring and carrier machined, matched and run-in before shipment.
| Ratios | 3:1 – 10:1 (single stage) |
|---|---|
| Rated torque | 120 – 850 Nm by frame size |
| Backlash | ≤ 8 arc-min standard, ≤ 3 arc-min optional |
| Lead time | 5 – 6 weeks |
A complete planetary stage from one accountable supplier: we cut the sun, planets and ring gear, machine the carrier, then assemble, lap and run each unit on the test bench before it ships.
Standard ratios from 3:1 to 10:1 in three frame sizes, with custom ratios and mounting interfaces available under the made-to-print program. Each assembly ships with a run-in report including backlash, transmission error and temperature-rise data.
