Precision Ground Helical Gear Set
$240 – $680
Matched pinion-and-wheel sets, case-hardened and ground to AGMA Class 11, crowned for quiet high-load running.
| Module range | 1 – 6 |
|---|---|
| Material | 8620 case-hardening steel |
| Quality class | AGMA 11 / DIN 5 |
| Lead time | 3 – 4 weeks |
Our best-selling configuration for industrial drives: a carburized 8620 steel pinion and wheel, ground as a matched set on the same Reishauer cell and shipped with paired inspection charts.
Standard sets cover module 1–6 with helix angles to 30°; lead crowning and tip relief are applied per your load spectrum, or per our recommendation if you share the duty cycle. Each set includes heat-lot material certs and a serialized FAI-style dimensional report.
